Crosby Straightpoint Running Line Dynamometer

About the Crosby Straightpoint Running Line Dynamometer

The TIMH range is a Wireless Running Line Dynamometer or RLTM built with dockside, marine, offshore, towage and salvage applications in mind. It is particularly useful where there is no anchor or dead end on the line to rig a Straightpoint Radiolink or Loadlink digital dynamometer to measure tension force at speeds up to 20m/min or 65ft/min.
Long-range 2.4GHz version providing industry leading wireless range of 700m or 2300ft to SP's SW-HHP handheld or software options.
The TIMH is constructed from marine grade stainless steel and is suitable for many wire rope configurations up to 80t and will, as an option, calculate lineout and speed in metres or feet. The TIMH has several mounting points featured in its unique design but if other mounting options are required Straightpoint can provide a custom engineered solution specific to your application.

Crosby Straightpoint Running Line Dynamometer features -

• Measure tension, line speed and distance
• Five wheel design improving accuracy
• Cabled or wireless options
• Easy to install and replace batteries (4 x AA standard Alkaline)
• Fully constructed from corrosion resistant stainless steel
• IP67/NEMA6 Loadpin
• Software available to data log and monitor or analogue output

Model	Weighing Capacity (Max) te	Resolution (d) te	Wire Rope Ø (mm)
MTIMH10TRD	10	0.01	4 - 19
TIMH10TRD	10	0.01	13 - 19
TIMH25RD	25	0.02	16 - 26
TIMH56TRD	56	0.05	28 - 38
TIMH80TRD	80	0.1	40 - 52
TIMH150TRD	150	0.2	52 - 89
