Ohaus DF 5000 Mild Steel Floor Scales

The Ohaus Defender 5000 Floor Scales are German built for the most demanding of industrial applications giving a solid lineup of floor and pit mount applications. Painted steel platform, IP67 stainless steel junction box with top access, available as floor or pit mounted, (pit frames and ramps available) powered by four stainless steel IP68 OIML R60 hermetically sealed load cells. Complete with the OhausTD52P Multifunctional indicator with large backlit display, Alphanumeric keypad and function keys which allow for a simplified user experience. The TD52P is housed within an ABS plastic enclosure and has a powder-coated steel mounting bracket. RS232 is standard and has optional interfaces RS232/RS485/USB device, Ethernet and Bluetooth/WiFi, Analog Output and Discrete I/O with relays. Applications include - Weighing, Parts Counting, Percent Weighing, Checkweighing, Dynamic Weighing (Display Hold).
Ohaus DF 5000 Standard Features:
•Indicator Guides The User with On-Screen Prompts
See results clearly on the large backlit display. The alphanumeric keypad and function keys
allow for a simplified user experience. On-screen prompts and soft keys will guide you
through the operation.
•Multiple Connectivity Options for Convenient Data Transfer and Storage
Results can be stored in the Micro SD card. Data output via built-in RS232 or optional
interfaces including RS232/RS485/USB device, Ethernet and Bluetooth/WiFi, Analog
Output and Discrete I/O with relays.
•Multiple Application Modes and High Storage Capacity for Greater Flexibility
Features common industrial modes and supports a 50,000 item library and 1,000 user
profiles which can be downloaded/uploaded for easy set-up (with SD Card.) Also equipped
with GMP/GLP capability with time/date for result traceability.
•Install Easily with the ‘EasyConnect’ Feature
When connecting to Defender 5000 bases, the EasyConnect™ technology allows instant
connection and use of the scale without extra configuration.

Standard Models

Model	Weighing Capacity (Max) (kg)	Readability (d) g	Weigh Plate (mm)	Code
DF52P300F1S	300	50	800 x 800 x 90	30525380
DF52P600F1S	600	100	800 x 800  x 90	30525381
DF52P300F1R	300	50	1000 x 1000 x 90	30525382
DF52P600F1R	600	100	1000 x 1000 x 90	30525383
DF52P1500F1R	1500	200	1000 x 1000 x 90	30525384
DF52P600F1LX	600	100	1500 x 1250 x 90	30525385
DF52P1500F1LX	1500	200	1500 x 1250 x 90	30525386
DF52P3000F1LX	3000	500	1500 x 1250 x 90	30525387
DF52P600F1X	600	100	1500 x 1500 x 90	30525388
DF52P1500F1X	1500	200	1500 x 1500 x 90	30525389
DF52P3000F1X	3000	500	1500 x 1500 x 90	30525390
DF52P1500F1XV	1500	200	2000 x 1500 x 90	30525391
DF52P3000F1XV	3000	500	2000 x 1500 x 90	30525392

Trade Approved Models

Model	Weighing Capacity (Max) (kg)	Readability (d) (e) g	Weigh Plate (mm)	Code
DF52P300F1S-M	300	100	800 x 800 x 90	30525425
DF52P600F1S-M	600	200	800 x 800 x 90	30525426
DF52P300F1R-M	300	100	1000 x 1000 x 90	30525427
DF52P600F1R-M	600	200	1000 x 1000 x 90	30525428
DF52P1500F1R-M	1500	500	1000 x 1000 x 90	30525429
DF52P600F1LX-M	600	200	1500 x 1250 x 90	30525430
DF52P1500F1LX-M	1500	500	1500 x 1250 x 90	30525431
DF52P3000F1LX-M	3000	1000	1500 x 1500 x 90	30525432
DF52P600F1X-M	600	200	1500 x 1500 x 90	30525433
DF52P1500F1X-M	1500	500	1500 x 1500 x 90	30525434
DF52P3000F1X-M	1500	500	2000 x 1500 x 90	30525435
DF52P1500F1XV-M	1500	500	2000 x 1500 x 90	30525436
DF52P3000F1XV-M	3000	1000	2000 x 1500 x 90	30525437
